– Apply sealant - D 176 501 A1- on sealing flange as shown and
install.
Note
The sealing flange must be installed within 5 minutes after sealant
application.
– Tighten bolts in 3 stages as follows:
A - Pre-tighten bolts -1- to 5 Nm.
B - Tighten bolts -2- to 23 Nm.
C - Tighten bolts -1- to 10 Nm.
Continue installation in the reverse order of removal, observing
the following:
– Install crankshaft oil seal ⇒ page 38 .
– Install sump ⇒ page 119 .
– Install drive plate ⇒ page 45 .
– Install engine with gearbox.
2.5 Renewing crankshaft sealing flange, vi‐
bration damper side
Special tools and workshop equipment required
♦ Torque wrench - V.A.G 1331-
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
2. Sealing flanges and drive plate 43
