4 Coolant
WARNING
The cooling system is under pressure when the engine is hot!
Danger of scalding by steam and hot coolant.
Cover filler cap on expansion tank with a cloth and open care‐
fully to release pressure.
⇒ “4.1 Draining coolant”, page 154 .
⇒ “4.2 Draining cooling system (vehicles with one heat exchang‐
er)”, page 155 .
⇒ “4.3 Draining cooling system (vehicles with two heat exchang‐
ers)”, page 156 .
⇒ “4.4 Filling with coolant”, page 158 .
⇒ “4.5 Checking filling quality”, page 161 .
⇒ “4.6 Checking cooling system for leaks”, page 162 .
4.1 Draining coolant
Caution
If large components (e.g. engine, radiator etc.) are to be re‐
moved/installed, it is absolutely necessary to drain the cooling
system ⇒ page 155 . Otherwise, hidden air bubbles can result
in incorrect filling. This results in temperature problems in the
cooling system and heating circuit.
– Remove noise insulation ⇒ General body repairs, exterior;
Rep. gr. 50 ; Assembly overview - noise insulation .
– Place drip tray - VAS 6208- beneath engine.
WARNING
The cooling system is under pressure when the engine is hot!
Danger of scalding by steam and hot coolant.
Cover filler cap on expansion tank with a cloth and open care‐
fully to release pressure.
– Open filler cap on coolant expansion tank.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
154 Rep. gr.19 - Cooling
