5 Radiator and radiator fans
⇒ “5.1 Assembly overview - radiator and radiator fan”,
page 164
⇒ “5.2 Removing and installing radiator module”, page 165
⇒ “5.3 Removing and installing radiator cowl”, page 170
⇒ “5.4 Dismantling cooler module”, page 171
WARNING
Danger of injury; the radiator fans can run at any time.
♦ Disconnect electrical connectors before starting work in
the area of the radiator cowl.
5.1 Assembly overview - radiator and radiator fan
1 - Cooler module
❑ With condenser and
ATF cooler
2 - Radiator cowl
❑ Removing and installing
⇒ page 170
3 - Radiator fan - V7-
❑ Remove together with
radiator cowl
4 - Rubber mounting
❑ For radiator mounting
5 - Lower radiator mounting
6 - Bolts
❑ 25 Nm
7 - Upper radiator mounting
8 - Rubber mounting
❑ For radiator mounting
9 - Bolt
❑ 5 Nm
10 - Locking pin
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
164 Rep. gr.19 - Cooling
