Installing:
– Apply a small amount of sealant - D 454 300 A2- to cover at
marked positions -arrows-.
– Fit cylinder head cover and tighten equally from inside out
-1 to 17-.
Perform further installation in reverse order, paying attention to
the following:
Note
♦
Renew cylinder head cover if damaged or leaking.
♦
Bolt intake manifold first to cylinder head. Then tighten the two
bolts of intake manifold support.
♦
Ensure fuel hoses are seated correctly.
– If necessary fill with coolant ⇒ page 158 .
Specified torques
Bolted connection Specified torque
Cylinder head cover to cylinder head 10 Nm
Upper part of intake manifold to lower part of
intake manifold
10 Nm
Further specified torques ⇒ “4.1 Assembly
overview - in‐
take manifold”,
page 233
2.4 Assembly overview - mechanical vacuum pump
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
92 Rep. gr.15 - Cylinder head, valve gear
