– Place camshaft timing chain »tightly« onto sprocket of high-
pressure pump and then bolt-on the guide rail -arrow-.
Further assembly is basically a reverse of the dismantling se‐
quence.
– Install camshaft adjuster with camshaft timing chain
⇒ page 69 .
– Install cylinder head cover and intake manifold ⇒ page 236 .
Note
It is not necessary to retighten cylinder head bolts after repairs.
2.3 Removing and installing cylinder head cover
Special tools and workshop
equipment required
♦ Pliers for spring-type clips - VAS 5024 A-
♦ Torque wrench - V.A.G 1331-
♦ Assembly tool - T10118-
♦ Puller - T10095 A-
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
90 Rep. gr.15 - Cylinder head, valve gear
