– Pull fuel lines -1- and -2- off fuel filter housing.
Note
To do this, press buttons on line couplings.
– Remove fuel filter out of opening in fuel tank.
– Empty fuel filter housing.
Installing:
Installation is carried out in the reverse order. When installing,
note the following:
– Renew flange seal.
– Ensure that connector for fuel gauge sender, earth wire and
fuel lines on fuel filter are properly seated.
– Insert flange of fuel filter in direction of travel -arrow-.
Lug -2- must stay between tabs -1- and -3- of fuel tank.
– Use special socket - T10202- to tighten locking ring to 145 Nm.
2.5 Emptying fuel tank
Special tools and workshop equipment required
♦ Fuel extractor - VAS 5190-
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
2. Parts of fuel supply system 181
