♦ Special wrench - T10202-
Caution
Risk of damage to the flaps in fuel filler neck by suction hose
of fuel extractor! The fuel tank may only be drained via the
flanges.
Procedure:
– Note safety precautions before starting installation work
⇒ page 173 .
– Observe rules for cleanliness ⇒ page 175 .
– Remove rear bench seat ⇒ General body repairs, interior;
Rep. gr. 72 ; Removing and installing bench seat .
– Fold right-hand carpet cut-out to the side.
– Remove securing nuts -1 to 4- of flange cover.
– Remove flange cover.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
182 Rep. gr.20 - Fuel supply system
