14 - Oil pipe
15 - 8 Nm
❑ Install with locking fluid
16 - Baffle plate
17 - Oil drain plug, 30 Nm
❑ With captive seal
❑ Renew
18 - Sump
❑ Clean sealing surface before fitting.
❑ Install with silicone sealant - D 176 501 A1- .
❑ Removing and installing ⇒ page 119
19 - Oil level and oil temperature sender - G266-
❑ Checking ⇒ Current flow diagrams, Electrical fault finding and Fitting locations
20 - 10 Nm
21 - Securing bolts for oil sump
❑ Sump/cylinder block 12 Nm
❑ Sump/gearbox 45 Nm
22 - 10 Nm
23 - Oil filter housing/left engine support
❑ Assembly overview - oil filter housing ⇒ page 128
❑ Connection diagram for coolant hoses ⇒ page 135
24 - 23 Nm
25 - Oil pressure switch
❑ Checking ⇒ page 131
26 - Seal
❑ Renew
❑ Lubricate before assembling.
27 - Seal
❑ Renew
❑ Lubricate before assembling.
1.2 Engine oil:
Oil capacities
♦ without oil filter 5.8 l.
♦ With oil filter 6.7 l
Engine oil specifications:
⇒ Maintenance ; Booklet ; Service tables
Check engine oil level with oil gauge tester - T40178-
⇒ page 118 .
1.2.1 Check engine oil level with oil gauge
tester - T40178-
Checking engine oil level in infotainment display ⇒ Maintenance ;
Booklet ; Engine oil level: check .
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
118 Rep. gr.17 - Lubrication
