– Remove drive plate again and fit appropriate shim -1-.
Note
Only one shim of the appropriate thickness may be used for com‐
pensation.
When specification is attained:
– Insert new securing bolts and tighten by hand.
– Tighten securing bolt to 60 Nm + turn 90° further.
2.7 Removing and installing bracket for an‐
cillaries
Removing:
Proceed as follows:
– Remove poly V-belt ⇒ page 34 .
– Remove alternator ⇒ Rep. gr. 27 .
– Remove power-assisted steering pump ⇒ Rep. gr. 48 .
– Remove air conditioner compressor ⇒ Rep. gr. 87 .
– Unscrew bolts -1 to 5- and remove ancillary bracket.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
2. Sealing flanges and drive plate 47
