♦ Counter-hold tool - T10172- with adapter - T10172/1-
♦ Torque wrench - V.A.G 1332-
Removing:
Proceed as follows:
– Remove gearbox ⇒ Automatic gearbox 0C8 - 8-speed; Rep.
gr. 37 .
– Lock vibration damper using counterhold - T10172- .
– Loosen drive plate securing bolts diagonally and remove.
– Remove drive plate.
Installing:
– Fit drive plate on crankshaft.
– Insert at least 3 old securing bolts and tighten to 30 Nm.
– Measure dimension -a- using depth gauge . Specification:
21.0 to 23.0 mm.
If specification is not attained:
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
46 Rep. gr.13 - Crankshaft group
