– The gap between markings of camshaft adjuster must be ex‐
actly 16 rollers of camshaft timing chain.
If the markings do not align:
– Adjust valve timing ⇒ page 74 .
If the markings align:
– Install cylinder head cover ⇒ page 90 .
– Install upper part of intake manifold ⇒ page 236 .
Markings on timing housing on FSI engines
-A- View from flywheel end
-B- View from vibration damper end
The markings on camshaft adjusters must align with notches
-arrows-.
1.2 Removing and installing camshaft adjuster
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
64 Rep. gr.15 - Cylinder head, valve gear
