7 - Bolt
❑ 10 Nm
7.2 Removing and installing high-pressure
pump
Special tools and workshop equipment required
♦ Insert tool - T10347-
♦ Socket - T10456-
Removing:
– Remove coolant hoses -1- and -2- from intake manifold.
WARNING
♦ The fuel system is pressurised! Wear protective goggles
and protective clothing to avoid injury and contact with the
skin. Before loosening fuel pipes, wrap a cloth around the
connection. Then release pressure by carefully loosening
the connection.
– Disconnect electrical connectors -arrows- and remove intake
manifold flap valve - N316- -A-.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
