4.3 Piston and cylinder dimensions
Honing dimen‐
sion
Piston ∅ Cylinder bore ∅
Basic dimension mm 88.945 89.010
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
4. Pistons and conrods 61
