– Fold right-hand carpet cut-out to the side.
– Remove securing nuts -1 to 4- of flange cover.
– Remove flange cover.
– Release connector -arrow- from flange of fuel filter.
– Use special socket - T10202- to unscrew locking ring from
flange.
– Slightly lift flange of fuel filter and disconnect connector -1-
from fuel gauge sender.
Note
♦ Draw off fuel, if necessary ⇒ page 181
♦ Earth wire -2- can remain connected.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
180 Rep. gr.20 - Fuel supply system
