– Bend end of cylinder head gasket down very slightly
-arrows-, just far enough to be able to clean upper sealing
surface on cylinder head gasket and cylinder head.
– Clean top and bottom of cylinder head gasket; both faces must
be free of oil and grease.
– Cut off nozzle on tube at front marking (∅ of nozzle approx. 2
mm).
– Apply thin coating of sealant to upper and lower sealing sur‐
faces of cylinder head gaskets; to do this, bend cylinder head
gasket downwards very slightly -arrows-.
– To coat the surface between cylinder head and gasket use a
flat object, e.g. a feeler gauge.
– Apply thin bead of sealant -arrows- from below into both cor‐
ners between cylinder head gasket and cylinder block, so that
holes in cylinder head gasket are filled.
– Check if dowel sleeves for sealing flange are inserted in cyl‐
inder block.
