– In engine compartment, disconnect breather line -arrow- to
activated charcoal filter solenoid valve 1 - N80- .
– Connect adapter hose - KLI 9210/57- between activated char‐
coal filter solenoid valve 1 - N80- and breather line as illustra‐
ted.
– Connect measuring hose -G- from fuel system tester - KLI
9210- to adapter hose - KLI 9210/57- .
– Set valve -D- to “Hold”.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
6. Activated charcoal filter system (vehicles for USA and Canada) 209
