♦ Release lever - 80 - 200-
Removing:
– Remove air filter element ⇒ page 231 .
– Remove front right wheel housing liner ⇒ Rep. gr. 66 .
– Remove air duct -1- from lower part of air filter, working from
the wheel housing side.
– Unscrew bolt -1-. Pull air filter housing upwards out of the rub‐
ber bushes.
Installing:
Installation is carried out in the reverse order. When installing,
note the following:
♦ A clean air filter housing is essential.
♦ Water drainage hose must be installed correctly.
♦ When using compressed air to blow out the air filter housing,
observe the following: in order to avoid functional impairments,
cover the critical air-carrying components such as air pipes,
etc. with a clean cloth.
♦ Install front right wheel housing liner ⇒ Rep. gr. 66 .
♦ Install air filter element ⇒ page 231 ; to do this, observe all
notes concerning installation of air filter element.
