♦ Hand operated vacuum pump - VAS 6213-
⇒ “1.2 Vacuum hose connection diagram”, page 137
⇒ “1.3 Assembly overview - vacuum hoses”, page 138
Condition
• The intake manifold flap valve - N316- has been checked with
⇒ Vehicle diagnostic tester.
Test sequence
If the intake manifold flap valve - N316- is OK:
– Detach coolant hoses -A- and lever out cover -arrow-.
– Move slide ring -1- on hand-operated vacuum pump - VAS
6213- to position -A- for “vacuum”.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
4. Intake manifold 235
