– Support gearbox with engine and gearbox jack - V.A.G 1383
A- and attached gearbox support - T10337- as shown in dia‐
gram.
– Remove bolts -1 and 2- for gearbox carrier.
– Undo bolts -arrows- and remove gearbox carrier.
Note
-Items 1 and 2- can be disregarded.
– Remove front propshaft ⇒ Rep. gr. 39 .
– Undo bolt for catalytic converter of exhaust bank 2 -arrow-.
