– Unscrew nuts for engine mounting on left and right sides
-arrow-.
– Lift engine evenly with both spindles until threaded engine
mounting stud is »free«.
– Remove securing bolts for engine mounting. Remove engine
mounting.
Installing:
Assemble in reverse order of dismantling.
• Specified torques ⇒ page 27 .
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
28 Rep. gr.10 - Removing and installing engine
