♦ Fitting tool - T10122-
♦ Extractor hook - T20143-
Remove seal:
Proceed as follows:
– Remove gearbox ⇒ Automatic gearbox 0C8 - 8-speed; Rep.
gr. 37 .
– Remove drive plate ⇒ page 45 .
– Fit puller hooks - T20143/2- behind sealing lip of oil seal as
shown in illustration.
– Support puller hook - T20143/2- on sealing flange and lever
seal out in direction of -arrow-.
