– Place exhaust camshaft adjuster »32A« into camshaft timing
chain. Previously counted 16 rollers must lie between teeth at
arrow markings »24E« and »32A«.
– Connect camshaft adjuster »32A« with camshaft timing chain
onto exhaust camshaft. Observe the following when doing
this:
• The arrow -1- on camshaft adjuster »32A« must align with right
notch -2- of timing housing. Markings on timing housing
⇒ page 64 .
Note
It must be possible to easily position the exhaust camshaft ad‐
juster onto the exhaust camshaft. Move camshaft back and forth
slightly if necessary.
– Remove setting tool - T10363- from bearing shaft.
– Remove camshaft bar - T10068 A- .
– Install chain tensioner for camshaft timing chain -arrow-.
Specified torque: 50 Nm.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
70 Rep. gr.15 - Cylinder head, valve gear
