– Remove camshaft adjuster for inlet camshaft -1- ⇒ page 64 .
– Undo and remove bolt -3- for guide rail.
– Remove camshaft timing chain from chain drive sprocket.
– Pull out bearing shaft -4- and remove chain drive sprocket
-6-.
Installing:
Note
Coat faces of chain drive sprocket and bearing shaft with lubri‐
cating paste - G 052 723 A2- .
– Insert drive sprocket. The notch -arrow- must be on top.
– Coat bearing shaft with lubricating paste - G 052 723 A2- and
push it in. The bearing shaft fits in only one position.
– Secure position of high-pressure pump chain drive sprocket
using adjusting tool - T10363- . The marking -A- on the drive
cam for high-pressure pump must be on top.
– Fit camshaft timing chain onto chain drive sprocket. Ensure
the chain runs »tautly« against the guide rail.
– Tighten bolt -arrow- for guide rail.
– Install camshaft adjuster ⇒ page 69 .
– Installing high-pressure pump ⇒ page 249 .
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
1. Chain drive 79
