WAREMA climatronic
®
Installation Instructions
M
1 ~
123456789
97643
Supply line, onsite
230V AC / 50Hz/16A
3x1.5mm
2
Total current
per supply 15 A
X8
X4
E
6.2
E
6.1
P
E
5.2
P
E
5.1
E
4.2
E
4.1
ANW
N
L
PE
123456789
X9
PP
V1 V2 V3 V4 V5 V6
GLT
A
5.1
A
5.2
F3
6,3 AT
C
5/6
A
6.1
A
6.2
Pushbutton for
fan
Max. line length
200m
All pushbutton lines
JY(St)Y 2x2x0.8 mm ø
P
1
Fan and/or fan valve
You can download the
connection diagrams
and settings for the
fan types of various
manufacturers from
www.warema.de!
N
PE
Valve
Fan
L
L
PE
N
Pushbutton for
valve
P
1
Switch actuator
6M
Fig. 16 Connection example of fan and/or fan valve (2 different products)
