WAREMA climatronic
®
Installation Instructions
8.3.3 Sensor allocation
CAUTION
Changing these settings may impair the safety of the system or reduce its
effectiveness. Therefore, be sure that you are aware of the effects when you
make a change.
The sensors must be allocated to the channels for the control to function
properly. In doing so, you define how the sensors are used for controlling the
individual channels.
These variables are later evaluated by the safety and comfort functions when
triggering move commands and actions. Up to twelve measured values from
up to three weather stations can be assigned per channel. Of these, up to
four can be "Photo" values and the value that is currently the highest is deci-
sive. The photosensors are allocated to the installation location as follows:
Photo 1
(Dämmerung)
Photo 3
Photo 4
Photo 2
Fig. 29 Alignment of the photodiodes
Channels
