8.1.2.1 Display behaviour of the
climatronic
[Brightness for operation] (2...100%) [Brightness standby] (OFF...100%) [Standby mode] [Standby duration] (1...240min) —
0 3 15 16...255

Minutes
Last operating pro-
cedure
Dim to standby
brightness
Change to standby
mode, display start
menu or standby
Activate screen sa-
ver, display time
Fig. 27 Display behaviour
8.1.2.2 Creating and loading a
standby picture
The WAREMA climatronic display can show an picture of your choice for the
duration of the standby mode. To set up a standby picture, proceed as fol-
lows:
Preparing the image
 Open an image file in any image processing program.
 Change the image size to 320x240.
 Save the file in the bitmap format (.BMP) with a colour depth of 8 bit.
Converting the image
 Start the climatronic studio software.
 Load the prepared image using the "Select file" function.
 The image is displayed. If the size, colour depth or format is incorrect, an er-
ror message is output.
 Save the image in the main directory of the SD card using the '"Save file"
function. The image is named BILD.WRM.
System settings
