Parts Lists
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
5-16
Parts List 3.1A Frame (2 of 2)
Item Name Part Number
1Duplex Frame Guide -
2 Path Duplex Sheet -
3 Idle Feed M Bush -
4 Bushing Push P Plate -
5 Idle Feed Shaft -
6 Bar Coupling Lever 005N01146
7Clutch Spacer -
8 Feed Roller 022N02673
9 Electric Clutch (Registration Clutch) 121N01219
10 Electric Clutch (Pickup Clutch) 121N01265
11 96 Idle Exit Gear 007N01707
12 65 Exit Gear -
13 Gear BRKT Ground -
14 CST Locker PMO -
15 SAW P Plate -
16 Regi Feed Shaft -
17 Empty Actuator 120N00552
18 Regi Actuator -
19 Feed Actuator -
20 Registration Sensor 130N01574
21 Path EX Duplex Frame -
22 Bottom Frame Plate -
23 SCF M Idle Roller -
24 Harness Cap -
25 Duplex Swing Bracket -
26 23/23 RDCN Gear 35 Feed Actuator 007N01706
27 Exhaust Fan -
28 Shaft -
29 Decurler Roller Frame -
30 Paper BRKT Ground -
31 HVPS Ground -
32 LSU Bracket Ground -
33 HVPS 105N02248
34 Exit Roller Frame -
35 Antistatic Brush -
