Xerox Phaser 3330 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
5-17
36 Exit Sensor Holder 130N01669
37 19 DR Swing Gear 007N01705
38 LSU Bracket -
39 RIB TR Guide -
40 Transfer Roller 108R01469
41 Transfer Earth Plate -
42 Rotor Core -
43 TR Terminal -
44 Cable Clamp -
45 Pick Up Roller 130N01673
48 Controller Shield -
49 Rear Door & Bin Full Sensor Harness -
50 Inlet-1 AC Harness -
51 Right LSU Holder BRKT -
52 Left LSU Holder BRKT -
53 Extension Ground BRKT -
54 29 Idle Feed Gear 007N01827
55 Spring-TS 009N01653
56 Gear-Feed 20 022N02672
57 Fan-Type1 (SMPS Fan) 127N07834
Item Name Part Number

Xerox Phaser 3330 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 1200 x 1200 dpi
First Page Out Time	As fast as 6.5 seconds
Monthly Duty Cycle	Up to 80, 000 pages
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	850 sheets
Processor Speed	600 MHz
Memory	256 MB
Paper Output Capacity	150 sheets
Print Languages	PCL 5e, PCL 6, PostScript 3
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Maximum Paper Size	8.5 x 14 in (Legal)
Weight	10.6 kg
