Xerox Phaser 3330 Service Manual

Troubleshooting
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
2-32
03-450 Bypass Tray Paper
mismatch
Paper Type mismatch.
Paper Size mismatch.
If printing PC, ensure print
driver and tray guide
settings match. Load
requested paper in the
Bypass Tray.
Verify tray guide settings.
Paper
Mismatch
03-600 Memory Failure Memory access failure. Cycle printer power.
Re-seat Memory DIMM(s).
If the error persists install
a new Main Board:
• Phaser 3330 (PL 1.0.7,
Parts List 1.0 Phaser
3330 Main)
• WorkCentre 3335 and
3345 (PL 6.1.7, Parts
List 6.1 WorkCentre
3335/3345 Main).
Memory
Failure
03-601 EPC Memory is full Embedded FAX Job
transmit/receive failure.
Print Failure.
Scan to file or Email failure.
Fax Server failure.
Try sending again.
Reduce complexity.
Selecting different criteria
for the job
Memory
Failure
03-602 EPC Memory is
Temp orari ly Fu ll
Try sending again.
03-603 Job to large to fit in
EPC memory
Collate Copy Job failure. Wait while memory
resources are made
available to continue
scanning your job. Once
all sheets have been
scanned, touch Close,
reload your originals and
re-scan as many times as
is required to complete
your job. Or touch Cancel
Job to Cancel your job.”
03-800 Check SD Card Hard drive failure occurred.
Not running properly.
Power Off/Power On
If fault persists install a
new hard disk drive.
Error Error Message Cause Initial Action Go To

Xerox Phaser 3330 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 1200 x 1200 dpi
First Page Out Time	As fast as 6.5 seconds
Monthly Duty Cycle	Up to 80, 000 pages
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	850 sheets
Processor Speed	600 MHz
Memory	256 MB
Paper Output Capacity	150 sheets
Print Languages	PCL 5e, PCL 6, PostScript 3
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Maximum Paper Size	8.5 x 14 in (Legal)
Weight	10.6 kg
