Xerox Phaser 3330 Service Manual

Troubleshooting
Xerox Internal Use Only Phaser 3330 and WorkCentre 3335/3345
Service Manual
2-33
03-900 GUI to Main PWB
Communication
Fault
User Interface cannot
communicate with the Main
PWB.
Power off and power on
the machine.
If the error persists install
a new Main Board:
• Phaser 3330 (PL 1.0.7,
Parts List 1.0 Phaser
3330 Main)
• WorkCentre 3335 and
3345 (PL 6.1.7, Parts
List 6.1 WorkCentre
3335/3345 Main).
If problem persists install
a new User Interface:
• Phaser 3330 (PL 1.1,
Parts List 1.1 Phaser
3330 Top Cover)
• WorkCente 3334/3335
(PL 10.1.22, Parts List
10.1 WorkCentre
3335/3345 Control
Panel
03-901 UI System Failure Communications error
between the UI and Main
PWB.
Power off and power on
the machine.
If the error persists install
a new Main Board:
• Phaser 3330 (PL 1.0.7,
Parts List 1.0 Phaser
3330 Main)
• WorkCentre 3335 and
3345 (PL 6.1.7, Parts
List 6.1 WorkCentre
3335/3345 Main).
If problem persists install
a new User Interface:
• Phaser 3330 (PL 1.1,
Parts List 1.1 Phaser
3330 Top Cover)
• WorkCente 3334/3335
(PL 10.1.22, Parts List
10.1 WorkCentre
3335/3345 Control
Panel)
Error Error Message Cause Initial Action Go To

Xerox Phaser 3330 Specifications

General

Print Technology	Laser
Print Speed	Up to 42 ppm
Print Resolution	Up to 1200 x 1200 dpi
First Page Out Time	As fast as 6.5 seconds
Monthly Duty Cycle	Up to 80, 000 pages
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	850 sheets
Processor Speed	600 MHz
Memory	256 MB
Paper Output Capacity	150 sheets
Print Languages	PCL 5e, PCL 6, PostScript 3
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Maximum Paper Size	8.5 x 14 in (Legal)
Weight	10.6 kg
