Xerox Phaser 4620 User Manual

5/2011
3-5
Phaser 4600/4620 Printer Service Manual
IQ2, IQ3
Image Quality
Revision - Xerox Internal Use Only
Remove the Transfer Roller and check for surface contamination or excessive wear. The
Transfer Roller is good.
YN
Replace the Transfer Roller, REP 9.1.
Check for debris on the Laser Unit window or obstructions between the Laser Unit and Drum
Cartridge. The laser path is clear.
YN
Clear the laser path of obstructions.
Remove the Fuser. Check for damage or debris on the rollers. The Fuser rollers are good.
YN
Clean or replace as necessary;
• Heat Roller PL 10.11 Item 12
• Pressure Roller PL 10.11 Item 3
•Fuser PL 10.10 Item 1
Check connections between the IP Board and Laser Unit. The connections are secure.
YN
Secure the connections.
Replace the IP Board.
IQ3 Unfused Image
The printed image is not fully fused to the paper. The image rubs off easily. A cold environment
affects the warm-up time, while high humidity has an adverse effect on fusing. Also, media
weight and composition affect fusing performance.
Initial Actions
• Check the printing environment. A location that’s too cold or humid reduces fusing perfor-
mance.
• Inspect the media path for debris, such as staples, paper clips, and paper scraps.
• Verify that the media type is set correctly.
Procedure
WARNING
Do not touch the Fuser while it is hot.
Rub the image with a soft cloth or tissue. The image smears when rubbed.
YN
Perform SCP 6 Final Actions.
Replace the media with new, dry media from an unopened ream. Print a test print. The image
smears when rubbed.
YN
Perform SCP 6 Final Actions.
Check the Fuser thumbscrews. The Fuser thumbscrews are tight.
YN
Tighten the Fuser, cycle system power and reprint the test print.
Remove and inspect the Fuser (REP 10.10). The Fuser Heat and Pressure Rollers are good.
YN
Replace the Fuser or worn components:
• Fuser PL 10.10 Item 1
• Heat Lamp PL 10.11 Item 17
• Heat Roller and bearings PL 10.11 Item 12
• Pressure Roller PL 10.11 Item 3
• Thermistor PL 10.15 Item 3
• Thermostat PL 10.15 Item 4
Check the Fuser electrical connection. The connector is good.
YN
Repair or replace the harness.
Check connections to the Fuser Drive Board. Connections to the Fuser Drive board are
secure.
YN
Secure the connections between the Fuser Drive Board.
Replace the Fuser Drive Board REP 1.3.
A

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
