Phaser 4600/4620 Printer Service Manual
SCP 5, SCP 6
Service Call Procedures
Revision - Xerox Internal Use Only
Component Life
The design life of the major components are shown in Table 1. Environmental conditions and
actual use will vary these factors. The component life shown in Table 1 is for reference only.
HFSI
The High Frequency Service Items are shown in Table 2.
SCP 6 Final Actions
Final Actions are used to evaluate the total operation of the system and to identify the actions
required to complete the service call.
Procedure
Complete the following, if a fault is identified, return to SCP 4 Fault Analysis:
• Perform the end of call subsystem maintenance actions, SCP 5 Subsystem Maintenance.
• Exercise the machine in all modes, printing from all trays. If a fault message is displayed
or some other problem is evident, go to SCP 4 Fault Analysis.
• Make a print of a customer document.
• If any of the customers selections were changed, return them to the customers preferred
settings. Refer to GP 4 System Administration Tools.
• At the first service and at any subsequent service where changes are made or options are
added, print the configuration report and store it with machine log book. Discard any pre-
vious versions of the configuration report.
• Remove and destroy any copies of test patterns.
• Ensure the machine and service area are clean before leaving the customer premises.
• Provide customer training if required.
Table 1 Component Life Expectancies
Item Description Print Life
1. Pick and nudger Rollers 200,000 pages
2. Separator Roller 100,000 pages
3. Transfer Roller 100,000 images
4. Fuser 200,000 images
5. Feed Roller 100,000 pages
Table 2 High frequency service items
Item Description
Recommended
life Reference
Drum Cartridge The total sides of copies and prints
after the last HFSI reset.
10k impressions PL 9.10 Item 1
Tray 1 Pick Roller Sheets fed from Tray 1 after last
HFSI reset.
150k feeds PL 8.10 Item 3
Tray 2 Pick Rollers Sheets fed from Tray 2 after last
HFSI reset.
200k feeds PL 8.15 Item 10
Transfer Roller Total prints after the last HFSI
reset.
100k impressions PL 9.10 Item 2
Fuser Total prints after the last HFSI
reset.
200k impressions PL 10.10 Item 1

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
