Xerox Phaser 4620 User Manual

5/2011
2-61
Phaser 4600/4620 Printer Service Manual
12-715-00, 12-716-00, 12-725-00, 12-726-00
Status Indicator RAPS
Revision - Xerox Internal Use Only
12-715-00, 12-716-00 Front Jogger Home Fault RAP
12-715-00 The left tamper did not move from home position as indicated by the Left Tamper
Home Position Sensor.
12-716-00 The left tamper did not move to home position as indicated by the Left Tamper
Home Position Sensor.
BSD-Reference: WD 17
Initial Actions
• Check for obstructions blocking tamper motion.
• Cycle system power.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
NOTE: Remove the Finisher top cover, REP 12.18 to access the tamper motor and left cover
REP 12.1 to access the Left Tamper Home Position Sensor.
Select dC330 code 12-815 to test the Left Tamper Home Position Sensor. The sensor signal
changes (high/low).
YN
Remove the Finisher, GP 14 to check the condition of the Finisher option connector, sen-
sor and harness. The sensor is connected and the harness undamaged.
YN
Replace the sensor (REP 12.10), or repair the harness.
Replace the Finisher Control Board, REP 12.2.
Select dC330 code 12-300 to test the tamper motor, PL 12.35 Item 19. The motor rotates
(on/off).
YN
Check the tamper motor connection and harness. Repair or reconnect as necessary.
Check the Finisher option harness in the Finisher Right Cover. The harness is undamaged.
YN
Repair the harness.
Replace these components in order until the error is corrected.
1. IOT Upper Option Harness, PL 10.30 Item 24
2. MCU Board, PL 3.10 Item 3
12-725-00, 12-726-00 Rear Jogger Home Fault RAP
12-725-00 The right tamper did not move from home position as indicated by the Right Tamper
Home Position Sensor.
12-726-00 The right tamper did not move to home position as indicated by the Right Tamper
Home Position Sensor.
BSD-Reference: WD 17
Initial Actions
• Check the stacker full sensor actuator.
• Check for obstructions blocking actuator motion.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
NOTE: Remove the Finisher top cover, REP 12.18 to access the tamper motor and left cover
REP 12.1 to access the Left Tamper Home Position Sensor.
Select dC330 code 12-820 to test the Right Tamper Home Position Sensor. The sensor sig-
nal changes (high/low).
YN
Remove the Finisher, GP 14 to check the condition of the Finisher option connector, sen-
sor and harness. The sensor is connected and the harness undamaged.
YN
Replace the sensor (REP 12.10), or repair the harness.
Replace the Finisher Control Board, REP 12.2.
Select dC330 code 12-320 to test the tamper motor, PL 12.35 Item 19. The motor rotates
(on/off).
YN
Check the tamper motor connection and harness. Repair or reconnect as necessary.
Check the Finisher option harness in the Finisher Right Cover. The harness is undamaged.
YN
Repair the harness.
Replace these components in order until the error is corrected.
1. IOT Upper Option Harness, PL 10.30 Item 24
2. MCU Board, PL 3.10 Item 3

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
