Xerox Phaser 4620 User Manual

5/2011
2-21
Phaser 4600/4620 Printer Service Manual
04-730-00
Status Indicator RAPS
Revision - Xerox Internal Use Only
04-730-00 HCF Lift Error RAP
04-730-00 HCF Level Sensor did not change state within 13 seconds of Lift Motor activation.
NOTE: Optional Tray numbering varies by configuration. When testing HCF components, use
the dC330 codes appropriate for the HCF’s position. For example, if the configuration is 5 trays
and the 5th tray is the HCF, use Tray 5 control codes.
BSD-Reference: WD 16
Initial Actions
• Open and close the HCF Front Door.
• Check for obstructions blocking bottom plate movement.
Procedure
WARNING
Use safe handling procedures when removing the module. Refer to GP 15. The module
is heavy.
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Raise and lower the lower lift plate. The lower lift plate moves up and down smoothly.
YN
Repair or replace damaged components.
Check Pick Assembly (PL 8.25) motion. Pick assembly motion is good.
YN
Repair improper Pick Assembly motion.
Select dC330 code for the HCF position. The sensor is operational (high/low).
YN
Repair or replace the Level Sensor, REP 8.50.
Check the Lift Gear, PL 8.35 Item 4. The gear is undamaged and properly installed.
YN
Replace the Lift Gear, REP 7.8.
Test HCF Lift Motor operation by opening and closing the front door. The Lift Motor rotates.
YN
Remove the IOT, Tray 3 and Tray 4 from the HCF and check the HCF Option Harness, PL
7.25 Item 15. The harness is undamaged.
YN
Replace the harness ().
Check the IOT Lower Option Harness. The harness is undamaged.
YN
Replace the Lower Option Harness, REP 10.5.
Remove the Right Cover (), reseat CN2 on the Control Board and CN1, CN2 on the
Jumper Board, then retest. The Lift Motor rotates.
YN
Replace the Lift Motor, (), then retest. The Lift Motor rotates.
YN
Replace the Control Board, ().
Reassemble and perform SCP 6 Final Actions.
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. Feeder Assembly, PL 8.25 Item 16
2. Control Board, PL 7.25 Item 18
3. MCU Board, PL 3.10 Item 3
A
A

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
