Phaser 4600/4620 Printer Service Manual
07-230-00, 07-231-00, 07-310-00
Revision - Xerox Internal Use Only
Status Indicator RAPS
07-230-00, 07-231-00 Jam in Tray 3 RAP
07-230-00 Jam 0 at Tray 3. Media did not exit the Tray 3 Pick Assembly.
07-231-00 Check Tray 3 Feed Area. Media remains at the Tray 3 Take Away Sensor.
BSD-Reference: WD 13
Initial Actions
1. Check for obstructions in the media path.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Nudger, Feed, and Separator Rollers for excessive wear or contamination. The
rollers are undamaged and clean.
YN
Clean or replace the rollers.
Check for obstructions or debris in the media path. The media path is clear.
YN
Clear the media path of obstructions or debris.
Check Tray 3 Pick Assembly (PL 8.20 Item 17) motion. Pick assembly motion is good.
YN
Repair improper pick assembly motion.
Select dC330 code 08-830 to test the Feed Clutch. The clutch is engaged (on/off).
YN
Remove the Right Cover (REP 7.25) and reseat CN9 on the Feeder Board, then retest.
The clutch is engaged.
YN
Replace the Feed Clutch, REP 8.41.
Reassemble and perform SCP 6 Final Actions.
Select dC330 code 08-930 to test the Feed Drive Assembly. The assembly rotates (on/off).
YN
Remove the Right Cover (REP 7.25) and reseat CN7 on the Feeder Board, then retest.
The Feed Drive Assembly rotates.
YN
Replace the Feed Drive Assembly, REP 8.42.
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. Feed Assembly, PL 8.40 Item 10
2. Pick Assembly, PL 8.20 Item 17
07-310-00 Paper Empty at Tray 4
07-310-00 The Tray 4 No Paper Sensor indicates Tray 4 is empty.
BSD-Reference: WD 13
Initial Actions
1. Check the No Paper Sensor Actuator.
2. Check for obstruction of the Pick mechanism.
Procedure
WARNING
Use safe handling procedures when removing the module. Refer to GP 15. The module
is heavy.
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the No Paper Sensor Actuator. The actuator is undamaged and motion is good.
YN
Repair or replace the Tray 4 No Paper Sensor Actuator.
Select dC330 code 07-410 to test the sensor. The sensor signal changes (high/low).
YN
Remove the IOT and Tray 3. Check the option harness connections. The harness con-
nectors are undamaged.
YN
Replace any damaged harnesses.
Reassemble the system to exchange Feeder positions. The error changes to the new
feeder position.
YN
Check the IOT Lower Option Harness. The harness is undamaged.
YN
Replace the Lower Option Harness, REP 10.5.
Replace the MCU Board, REP 3.4.
Replace the No Paper Sensor (REP 7.35), then retest. The signal changes.
YN
Remove the Right Cover (REP 28.2) and reseat CN3 on the Feeder Board, then
retest. The sensor signal changes.
YN
Replace the Feeder Board, REP 7.28.
Reassemble and perform SCP 6 Final Actions.
Reassemble and perform SCP 6 Final Actions.
Replace the MCU Board, REP 3.4.
