Xerox Phaser 4620 User Manual

5/2011
2-22
Phaser 4600/4620 Printer Service Manual
04-810-00, 04-930-00
Revision - Xerox Internal Use Only
Status Indicator RAPS
04-810-00 Rear Fan Failure RAP
04-810-00 The Rear Door Fan has failed.
BSD-Reference: WD 7
Initial Actions
• Close the Rear Door.
• Check for obstructions blocking fan rotation.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Perform SCP 6 Final Actions.
Select dC330 code 10-500 to test the Rear Fan. The Fan rotates.
YN
Replace the Fan, REP 28.7, then retest. The Fan rotates.
YN
Check the Rear Door connection P/J63. The connector is undamaged.
YN
Repair or replace the Rear Door, REP 28.6.
Remove the Right Cover (REP 28.2) and check CN4 on the Joint Board. The con-
nection is secure.
YN
Secure the connections.
Replace these components in order until the error is corrected.
1. Rear Door, PL 28.25 Item 1
2. Joint Board, PL 9.15 Item 7
3. Exit Assembly, PL 10.30 Item 25
Reassemble and perform SCP 6 Final Actions.
Reassemble and perform SCP 6 Final Actions.
04-930-00 Main Fan Failure RAP
04-930-00 The SMPS Fan has failed.
BSD-Reference: WD 8
Initial Actions
• Check for obstructions blocking fan rotation.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Perform SCP 6 Final Actions.
Select dC330 code 04-120 to test the SMPS Fan. The Fan rotates.
YN
Replace the Fan, REP 28.7, then retest. The Fan rotates.
YN
Remove the Left Cover (REP 28.3) and check CN1 on the Joint Board. The con-
nection is secure.
YN
Secure the connections.
Replace these components in order until the error is corrected.
1. SMPS Fan, PL 1.15 Item 6
2. Joint Board, PL 9.15 Item 7
Reassemble and perform SCP 6 Final Actions.
Reassemble and perform SCP 6 Final Actions.

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
