Xerox Phaser 4620 User Manual

5/2011
1-8
Phaser 4600/4620 Printer Service Manual
SCP 7
Revision - Xerox Internal Use Only
Service Call Procedures
SCP 7 Configurations and Options
Configurations and Options
Refer to Table 1 for basic configurations and options. This service manual covers all configura-
tions. Within this manual ignore any references to options that are not installed.
Table 1 Phaser 4600/4620 Configurations
Features 4600N 4600DN 4600DT 4620DN 4620DT
Processor Speed 700 MHz 700 MHz 700 MHz 700 MHz 700 MHz
Memory* 256 MB 256 MB 256 MB 256 MB 256 MB
Print Speed 55 ppm, Letter
52 ppm A4
55 ppm, Letter
52 ppm, A4
55 ppm, Letter
52 ppm, A4
65 ppm, Letter
62 ppm, A4
65 ppm, Letter
62 ppm, A4
PS3 Fonts (136) Standard Standard Standard Standard Standard
PCL6 Fonts (80 Scalable, 9 Bitmap) Standard Standard Standard Standard Standard
USB 2.0 Standard Standard Standard Standard Standard
Ethernet Interface 10/100 Base-TX 10/100 Base-TX 10/100 Base-TX 10/100 Base-TX 10/100 Base-TX
Tray 1 (100 sheet) Standard Standard Standard Standard Standard
Tray 2 (520 sheet) Standard Standard Standard Standard Standard
Tray 3 (520 sheet) Optional Standard Standard Optional Standard
Tray 4 (520 sheet) Optional Optional Optional Optional Optional
Tray 5 (2000 / 520-sheet) Optional Optional Optional Optional Optional
Tray 6 (520-sheet) Optional Optional Optional Optional Optional
Duplex Not available Standard Standard Standard Standard
Mailbox (4-bin) Optional Optional Optional Optional Optional
Finisher Optional Optional Optional Optional Optional
Hard Disk Drive Optional Optional Optional Optional Optional
Printer Stand Optional Optional Optional Optional Optional
Wireless LAN Optional Optional Optional Optional Optional
Printer Resolution 600 x 600 dpi
1200 Class
600 x 600 dpi
1200 Class
600 x 600 dpi
1200 Class
600 x 600 dpi
1200 Class
600 x 600 dpi
1200 Class
* All configurations have one memory slot supporting a 512 MB DDR2 DIMM, to a maximum 768 MB total.

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
