2-11
Phaser 4600/4620 Printer Service Manual
03-420-00, 03-430-00
Status Indicator RAPS
Revision - Xerox Internal Use Only
03-420-00 Tray 3 Paper Mismatch RAP
03-420-00 Media size setting for Tray 3 differ from those reported by the Size Switch.
BSD-Reference: WD 13
Initial Actions
• Check media size settings for the tray from the Control Panel.
• Reset the tray side and rear guides.
• Check for obstructions blocking the Size Switch.
Procedure
WARNING
Use safe handling procedures when removing the module. Refer to GP 15. The module
is heavy.
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Inspect the Tray 2 end guide. The end guide operates the Size Switch actuators.
YN
Replace the Tray,
Select dC330 codes 07-320, 07-330, 07-340. The switches are operational (high/low).
YN
Replace the Size Switch, REP 7.30.
Remove the IOT from the Feeder. Check the Tray 3 Upper Option Harness. The harness is
undamaged.
YN
Replace the Upper Option Connector, REP 7.31.
Check the IOT option connector. The harness is undamaged.
YN
Replace the Lower Option Harness, REP 10.5.
Replace these components in order until the error is corrected.
1. Size Switch, PL 3.10 Item 9
2. Tray, PL 7.10 Item 23
3. Feeder Board, PL 8.30 Item 7
4. MCU Board, PL 3.10 Item 3
03-430-00 Tray 4 Paper Mismatch RAP
03-430-00 Media size setting for Tray 4 differ from those reported by the Size Switch.
BSD-Reference: WD 13
Initial Actions
• Check media size settings for the tray from the Control Panel.
• Reset the tray side and rear guides.
• Check for obstructions blocking the Size Switch.
Procedure
WARNING
Use safe handling procedures when removing the module. Refer to GP 15. The module
is heavy.
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Inspect the Tray 4 end guide. The end guide operates the Size Switch actuators.
YN
Replace the Tray,
Select dC330 codes 07-420, 07-430, 07-440. The switches are operational (high/low).
YN
Replace the Size Switch, REP 7.30.
Remove the IOT and Tray 3 from the Feeder. Check the Tray 4 Upper Option Harness. The
harness is undamaged.
YN
Replace the Upper Option Harness, REP 7.31.
Check option harness continuity through Trays 3 and 4. The connectors are undamaged.
YN
Replace damaged connectors.
Check the IOT Lower Option Harness. The harness is undamaged.
YN
Replace the Lower Option Harness, REP 10.5.
Replace these components in order until the error is corrected.
1. Size Switch, PL 3.10 Item 9
2. Tray, PL 7.10 Item 23
3. Feeder Board, PL 8.30 Item 7
4. MCU Board, PL 3.10 Item 3

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
