Xerox Phaser 4620 User Manual

5/2011
2-6
Phaser 4600/4620 Printer Service Manual
03-115-00, 03-120-00, 03-940-00
Revision - Xerox Internal Use Only
Status Indicator RAPS
03-115-00 Mailbox Interface Error RAP
03-115-00 Communications between the Mailbox and IOT has failed.
BSD-Reference: WD 18
Initial Actions
• Reseat the Mailbox on the IOT connection.
• Check for obstructions or damage to the interface connection.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Remove the Mailbox right cover (REP 11.3) and check the option harness. The harness is
undamaged.
YN
Repair or replace the Mailbox option harness, PL 11.15 Item 4.
Check the IOT Upper Option Harness. The harness is undamaged.
YN
Replace the Upper Option Harness, REP 10.4.
Replace these components in order until the error is corrected.
1. Mailbox Control Board, PL 11.15 Item 1
2. MCU Board, PL 3.10 Item 3
03-120-00, 03-940-00 Tray 3 Communications Fault RAP
03-120-00 A communication error has occurred between the MCU Board and Tray 3.
03-940-00 A communication error has occurred between the MCU Board and Tray 3.
BSD-Reference: WD 15
Initial Actions
• Lock the feeder to the IOT.
• Reseat the IOT on the Feeder.
• Check for obstructions blocking the option harness.
Procedure
WARNING
Use safe handling procedures when removing the module. Refer to GP 15. The module
is heavy.
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Cycle system power. The error message is displayed.
YN
Complete.
Remove the IOT from the Feeder and check the Feeder Option Connector. The connector is
undamaged.
YN
Replace the Feeder Upper Option Harness, REP 7.31.
Check the Lower Option Harness. The harness is undamaged.
YN
Replace the Lower Option Harness, REP 10.5.
Replace these components in order until the error is corrected.
1. Feeder Board, PL 8.30 Item 7
2. MCU Board, PL 3.10 Item 3

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
