Xerox Phaser 4620 User Manual

5/2011
6-26
Phaser 4600/4620 Printer Service Manual
GP 22, dC131
Revision - Xerox Internal Use Only
General Procedures/Information
GP 22 Environmental Data
Environmental Specifications
dC131 NVM Read/Write
Purpose
To review and modify values within the machine configuration and control parameters stored in
NVM.
Description
Each NVM item is identified using a chain and location code in the form XX-XXX, where XX- is
the chain prefix, and -XXX is an identifier in the range 001 to 999. For example 05-100.
NOTE: Tray numbering is dynamic according to available configuration, such that the registra-
tion adjustments must be accomplished by adjusting the appropriate tray listed in the configu-
ration. For example, if the configuration is 5 trays and the 5th tray is the HCF, use Tray 5
registration adjustments for the HCF.
Procedure
1. Enter diagnostics, GP 1.
2. Select Diagnostic Routines.
3. Select the required dC routine category:
4. Select 131 NVM Read/Write.
5. Select the appropriate NVM chain.
6. View or edit the chain as necessary.
7. Refer to the tables that follow for NVM chain locations and parameters:
• Table 1 NVM chain 7
• Table 2 NVM chain 8
• Table 3 NVM chain 9
• Table 4 NVM chain 10
8. When the values of an editable NVM have been changed, switch off the machine, the
switch on the machine, to check and evaluate the changes made to the NVM.
Table 1 Environmental Specifications
Characteristic Specifications
Operating Storage
Temperature
15
º
to 32
º
C (59º to 86º F) -20
º
to 40
º
C (-4º to 104º F)
Humidity 20% to 80% RH Non-Condensing 10% to 90% RH, non-condensing
Acoustic Noise Operation Standby or Ready
Sound Pressure (Deci-
bels)
56.0 dB 30.0 dB
Table 1 NVM Chain 7
Location NVM Name NVM Description Value Default
07-100 Top Registration
Tray 1 Simplex
The changed dimension of Tray
1 top registration in simplex
0 ~ 60 (0.5mm / 13
steps)
30
07-110 Side Registration
Tray 1 Simplex
The changed dimension of Tray
1 side registration in simplex.
0 ~ 60 (0.5mm / 13
steps)
30
07-120 Top Registration
Tray 1 Dup_long
(2nd side)
1 top registration of 2nd side in
duplex long.
0 ~ 60 (0.5mm / 13
steps)
30
07-130 Side Registration
Tray 1 Dup_long
(2nd side)
The changed dimension of tray
1 side registration of 2nd side
in duplex long
0 ~ 60 (0.5mm / 13
steps)
30
07-140 Top Registration
Tray 1 Duplex
(1st side)
The changed dimension of tray
1 top registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
