Xerox Phaser 4620 User Manual

5/2011
6-27
Phaser 4600/4620 Printer Service Manual
dC131
General Procedures/Information
Revision - Xerox Internal Use Only
07-150 Side Registration
Tray 1 Duplex
(1st side)
The changed dimension of tray
1 side registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
07-200 Top Registration
Tray 2 Simplex
The changed dimension of Tray
2 top registration in simplex
0 ~ 60 (0.5mm / 13
steps)
30
07-210 Side Registration
Tray 2 Simplex
The changed dimension of Tray
2 side registration in simplex.
0 ~ 60 (0.5mm / 13
steps)
30
07-220 Top Registration
Tray 2 Dup_long
(2nd side)
1 top registration of 2nd side in
duplex long.
0 ~ 60 (0.5mm / 13
steps)
30
07-230 Side Registration
Tray 2 Dup_long
(2nd side)
The changed dimension of Tray
2 side registration of 2nd side
in duplex long
0 ~ 60 (0.5mm / 13
steps)
30
07-240 Side Registration
Tray 2 Duplex
(1st side)
The changed dimension of Tray
2 top registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
07-250 Top Registration
Tray 3 Simplex
The changed dimension of Tray
2 side registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
07-300 Top Registration
Tray 3 Simplex
The changed dimension of Tray
3 top registration in simplex
0 ~ 60 (0.5mm / 13
steps)
30
07-310 Side Registration
Tray 3 Simplex
The changed dimension of Tray
3 side registration in simplex.
0 ~ 60 (0.5mm / 13
steps)
30
07-320 Top Registration
Tray 3 Dup_long
(2nd side)
1 top registration of 2nd side in
duplex long.
0 ~ 60 (0.5mm / 13
steps)
30
07-330 Side Registration
Tray 3 Dup_long
(2nd side)
The changed dimension of Tray
3 side registration of 2nd side
in duplex long
0 ~ 60 (0.5mm / 13
steps)
30
07-340 Side Registra-
tion Tray 3
Duplex (1st side)
The changed dimension of Tray
3 top registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
07-350 Top Registration
Tray 3 Duplex
(1st side)
The changed dimension of Tray
3 side registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
07-400 Top Registration
Tray 4 Simplex
The changed dimension of Tray
4 top registration in simplex
0 ~ 60 (0.5mm / 13
steps)
30
07-410 Side Registration
Tray 4 Simplex
The changed dimension of Tray
4 side registration in simplex.
0 ~ 60 (0.5mm / 13
steps)
30
07-420 Top Registration
Tray 4 Dup_long
(2nd side)
1 top registration of 2nd side in
duplex long.
0 ~ 60 (0.5mm / 13
steps)
30
07-430 Side Registration
Tray 4 Dup_long
(2nd side)
The changed dimension of Tray
4 side registration of 2nd side
in duplex long
0 ~ 60 (0.5mm / 13
steps)
30
Table 1 NVM Chain 7
Location NVM Name NVM Description Value Default
07-440 Top Registration
Tray 4 Duplex
(1st side)
The changed dimension of Tray
4 top registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
07-450 Side Registra-
tion Tray 4
Duplex (1st side)
The changed dimension of Tray
4 side registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
07-500 Top Registration
Tray 5 Simplex
The changed dimension of Tray
5 top registration in simplex
0 ~ 60 (0.5mm / 13
steps)
30
07-510 Side Registration
Tray 5 Simplex
The changed dimension of Tray
5 side registration in simplex.
0 ~ 60 (0.5mm / 13
steps)
30
07-520 Top Registration
Tray 5 Dup_long
(2nd side)
1 top registration of 2nd side in
duplex long.
0 ~ 60 (0.5mm / 13
steps)
30
07-530 Side Registration
Tray 5 Dup_long
(2nd side)
The changed dimension of Tray
5 side registration of 2nd side
in duplex long
0 ~ 60 (0.5mm / 13
steps)
30
07-540 Top Registration
Tray 5 Duplex
(1st side)
The changed dimension of Tray
5 top registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
07-550 Side Registra-
tion Tray 5
Duplex (1st side)
The changed dimension of Tray
5 side registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
07-600 Top Registration
Tray 6 Simplex
The changed dimension of Tray
6 top registration in simplex
0 ~ 60 (0.5mm / 13
steps)
30
07-610 Side Registration
Tray 6 Simplex
The changed dimension of Tray
6 side registration in simplex.
0 ~ 60 (0.5mm / 13
steps)
30
07-620 Top Registration
Tray 6 Dup_long
(2nd side)
1 top registration of 2nd side in
duplex long.
0 ~ 60 (0.5mm / 13
steps)
30
07-630 Side Registration
Tray 6 Dup_long
(2nd side)
The changed dimension of Tray
6 side registration of 2nd side
in duplex long
0 ~ 60 (0.5mm / 13
steps)
30
07-640 Top Registration
Tray 6 Duplex
(1st side)
The changed dimension of Tray
6 top registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
07-650 Side Registra-
tion Tray 6
Duplex (1st side)
The changed dimension of Tray
6 side registration of 1st side in
duplex long and short.
0 ~ 60 (0.5mm / 13
steps)
30
Table 2 NVM Chain 8
Location NVM Name NVM Description Value Default
08-120 Tray 1 Pick Roller
life page counter
Number of Tray 1 sheets since
last reset. Read only.
Current count None
08-130 Tray 2 Pick Roller
life page counter
Number of Tray 2 sheets since
last reset. Read only.
Current count None
Table 1 NVM Chain 7
Location NVM Name NVM Description Value Default

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
