Status Indicator RAPS
09-300-00 Drum Warning RAP
09-300-00 The drum cartridge is near end of life.
BSD-Reference: WD 6
Initial Actions
• Check Drum Cartridge life count. Replace if at or near end of life.
• Reseat the Drum Cartridge.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Drum Cartridge life counter. Life count is at or near end of life.
YN
Cycle system power. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the Drum Cartridge. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Remove the Right Cover (REP 28.2) and reseat CN16 on the MCU Board. The error
message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the MCU Board, REP 9.8.
Replace the Drum Cartridge.
09-400-00 Replace Drum Cartridge RAP
09-400-00 The Drum Cartridge has reached end of life.
BSD-Reference: WD 6
Initial Actions
• Check Drum Cartridge life count. Replace if at or near end of life.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Drum Cartridge life counter. Life count is at end of life.
YN
Cycle system power. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the Drum Cartridge. The error message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Remove the Right Cover (REP 28.2) and reseat CN16 on the MCU Board. The error
message is displayed.
YN
Reassemble and perform SCP 6 Final Actions.
Replace the MCU Board, REP 9.8.
Replace the Drum Cartridge.
