5/2011
4-146
Phaser 4600/4620 Printer Service Manual
REP 12.24
Revision - Xerox Internal Use Only
Repairs
Figure 2 Remove, but do not disconnect the Stapler Assembly
7. Remove 3 screws (plastic) that secure the Stacker Shield Assembly to the Finisher, Fig-
ure 3.
Figure 3 Remove the Stacker Shield Assembly
To Next Page
