2-32
Phaser 4600/4620 Printer Service Manual
07-530-00, 07-531-00, 07-630-00
Revision - Xerox Internal Use Only
Status Indicator RAPS
07-530-00 Jam 0 in Tray 1 RAP
07-530-00 Media remains in the Tray 1 Feeder.
BSD-Reference: WD 5
Initial Actions
1. Check media condition.
2. Check for obstructions in the media path.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Feed and Separator Rollers for excessive wear or contamination. The rollers are
undamaged and clean.
YN
Clean or replace the rollers.
Check for obstructions or debris in the media path. The media path is clear.
YN
Clear the media path of obstructions or debris.
Select dC330 code 08-810 to test the Tray 1 Feed Clutch. The clutch is engaged (on/off).
YN
Remove the Right Cover (REP 28.2) and reseat CN13 on the MCU Board, then retest.
The clutch is engaged.
YN
Replace the Feed Clutch, REP 7.16.
Reassemble and perform SCP 6 Final Actions.
Select dC330 code 08-920 to test the Feed Drive. The Feed Drive Assembly rotates (on/
off).
YN
Remove the Right Cover (REP 28.2) and reseat CN12 on the MCU Board, then retest.
The Feed Drive Assembly rotates.
YN
Replace the Feed Drive Assembly, REP 4.4.
Reassemble and perform SCP 6 Final Actions.
Replace the MCU Board, REP 3.4.
07-531-00, 07-630-00 Jam in Tray 6 RAP
07-531-00 Check Tray 6 Feed Area. Media remains in the Tray 6 Take Away Sensor.
07-630-00 Jam 0 in Tray 6. Media remains at the Tray 6 Pick-up Assembly.
BSD-Reference: WD 13
Initial Actions
1. Check for obstructions in the media path.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Check the Nudger, Feed, and Separator Rollers for excessive wear or contamination. The
rollers are undamaged and clean.
YN
Clean or replace the rollers.
Check for obstructions or debris in the media path. The media path is clear.
YN
Clear the media path of obstructions or debris.
Check Tray 6 Pick Assembly (PL 8.20 Item 17) motion. Pick assembly motion is good.
YN
Repair improper pick assembly motion.
Select dC330 code 08-856 to test the Tray 6 Feed Clutch. The clutch is engaged (on/off).
YN
Remove the Right Cover (REP 7.25) and reseat CN9 on the Feeder Board, then retest.
The clutch is engaged.
YN
Replace the Feed Clutch, REP 8.41.
Reassemble and perform SCP 6 Final Actions.
Select dC330 code 08-960 to test the Feed Drive. The Feed Drive Assembly rotates (on/
off).
YN
Remove the Right Cover (REP 7.25) and reseat CN7 on the Feeder Board, then retest.
The Feed Drive Assembly rotates.
YN
Replace the Feed Drive Assembly, REP 8.42.
Reassemble and perform SCP 6 Final Actions.
Replace these components in order until the error is corrected.
1. Feed Assembly, PL 8.40 Item 10

Xerox Phaser 4620 Specifications

General

Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Color	No
I/O ports	10/100/1000 BaseT Ethernet, USB 2.0
Depth (min)	541 mm
Height (min)	420 mm
Minimum width	476 mm
Minimum weight	34.6 kg
Package length	698.49 mm
Print technology	Laser printing
Mac compatibility	Yes
Security features	Audit log, HTTPS, Image overwrite security, IP filtering, IPSec, Network authentication, SNMPv3, 802.1x
Storage drive type	Optional
Print memory (standard)	256 MB
Power consumption (active)	900 W
Minimum storage drive space	160 GB
Power consumption (standby)	93 W
Power consumption (PowerSave)	10 W
Storage media	HDD
Maximum internal memory	768 MB
Sound power level (standby)	39 dB
PCL fonts	93
Certification	Class 1 Laser Product, CE Marked, EMC Directive 89/336/EEC, EN 55022 Class B, EN 55024, FCC Part 15, Class B, Low Voltage Directive 73/23/EEC, RoHS Directive 2002/95/EC
Country of origin	China
Maximum duty cycle	275000 pages per month
Number of PostScript fonts	136
Number of print cartridges	1
Total input capacity	550 sheets
Total output capacity	500 sheets
Maximum input capacity	2000 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.8 s
Print speed (black, normal quality, A4/US Letter)	65 ppm
Display	LCD
Package weight	40200 g
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Labels, Pre-Printed, Recycled paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Width	627.37 mm
Height	685.79 mm
Dimensions (WxDxH)	476 x 420 x 541 mm
