Xerox WorkCentre 5945

February 2016
5-20
Xerox® WorkCentre® 5945 Family
PL 10.14
Parts Lists
PL 10.14 Exit Drive Assembly
Item Part Description
1
007K20735 Exit drive assembly (REP 10.2,
ADJ 40.1)
2 – Exit drive belt (P/O PL 10.14 Item
1)
3 – Belt (P/O PL 10.14 Item 1)
4 – Pulley (P/O PL 10.14 Item 1)
5 – Bearing (P/O PL 10.14 Item 1)
6 – Exit drive housing (P/O PL 10.14
Item 1)
7 – Drive shaft (P/O PL 10.14 Item 1)
8 – Drive gear (P/O PL 10.14 Item 1)
9 – Clutch gear (P/O PL 10.14 Item 1)
10 – Offset bearing (P/O PL 10.14 Item
1)
11 – Spring (P/O PL 10.14 Item 1)
