February 2016
5-69
Xerox® WorkCentre® 5945 Family
PL 31.14
Parts Lists
PL 31.14 Maintenance/Installation/
R
emoval Kits (3 of 3)
Item Part Description
1
– Initialisation kits (see below for
variants)
– – 45 ppm (Page pack enabled) (XE)
(Not Spared)
– – 55ppm (Page pack enabled) (XE)
(Not Spared)
– – 45 ppm (Speed only SIM) (XE)
(Not Spared)
– – 55 ppm (Speed only SIM) (XE)
(Not Spared)
– – 45 ppm (Speed only SIM) (USSG/
XCL) (Not Spared)
– – 55 ppm (Speed only SIM) (USSG/
XCL) (Not Spared)
– – 45 ppm (BIM - Speed only SIM)
(USSG/XCL) (Not Spared)
– – 55 ppm (BIM - Speed only SIM)
(USSG/XCL) (Not Spared)
– – 45 ppm (BIM - Page pack enabled)
(XE) (Not Spared)
– – 55 ppm (BIM - Page pack enabled)
(XE) (Not Spared)
2 – SIM kits (see below for variants)
– 604K96570 45 ppm (Page pack enabled) (XE)
– 604K96580 55 ppm (Page pack enabled) (XE)
– 607K09640 Billing impression mode (45 ppm)
– 607K09650 Billing impression mode (55 ppm)
3 607K04371 Left door repair kit
4 604K84190 FAR HCF bowl curl kit
5 497K13822 Horizontal transport kit
6 604K97710 Tray 3 front cover kit
7 600T02458 Left door damper spring tool kit
(See NOTE 2)
8 604K97721 Tray 4 front cover kit
9 497K11350 Power cord kit (USSG/XCL)
10 607K03160 Doc present sensor actuator kit (W/
TAG D-001)
11 604K96640 SPDH upper tray spares kit (W/
TAG D-002)
12 607K04310 Last sheet out sensor spares kit
(W/TAG D-002)
13 607K08290 Horizontal transport motor
grounding kit (W/TAG 005)
14 607K09420 SPDH Mylar kit (W/TAG 004)
15 607K09430 Separation assembly kit (W/TAG
004)
16 497K16170 RFID Card reader kit
NOTE: 1.Do not order 497/8K parts. 497/8K parts are
customer install kits and are shown for reference only.
NOTE: 2.Refer to GP 37 for correct use of these tools when
removing left door assembly.
