Xerox WorkCentre 5945

February 2016
5-38
Xerox® WorkCentre® 5945 Family
PL 12.325
Parts Lists
PL 12.325 LVF BM Docking Latch
Item Part Description
1
– Docking latch cover (Not Spared)
2 110K13980 Docking interlock switch (S12-177)
3 – Link bracket assembly (P/O PL
12.325 Item 7)
4 – Stopper (P/O PL 12.325 Item 7)
5 – Docking latch (P/O PL 12.325 Item
7)
6 – Latch hook (P/O PL 12.325 Item 7)
7 017K04761 Docking latch assembly (REP
12.16-150)
8 120K03450 Docking actuator
