Xerox WorkCentre 5945

February 2016
5-35
Xerox® WorkCentre® 5945 Family
PL 12.70
Parts Lists
PL 12.70 2K LCSS Entry Guide Cover/
J
am Clearance Guide
Item Part Description
1
032K09671 Jam clearance guide assembly
2 – Jam clearance handle (P/O PL
12.70 Item 1)
3 130E10380 Entry sensor (Q12-077)
4 – Sensor bracket (Not Spared)
5 – Entry guide cover (REF: PL 12.10
Item 3) (REP 12.15-110)
6 – Jam clearance guide (P/O PL 12.70
Item 1)
7 809E78390 Latch
