Xerox WorkCentre 5945

February 2016
5-82
Xerox® WorkCentre® 5945 Family
PL 70.26
Parts Lists
PL 70.26 Tray 3 and 4 Assembly
C
overs
Item Part Description
1
822E16692 Lower rear cover
2 – Not used
3 059K77240 Castor (locking)
4 – Tray 3 front cover (P/O PL 31.14
Item 6) (REP 70.5)
5 – Tray 4 front cover (P/O PL 31.14
Item 8) (REP 70.14)
6 – Castor (Not Spared)
7 822E15371 Lower left/right cover
