Xerox WorkCentre 5945

February 2016
5-49
Xerox® WorkCentre® 5945 Family
PL 12.380
Parts Lists
PL 12.380 LVF BM Booklet Tamper
A
ssembly
Item Part Description
1
090K02590 Booklet tamper assembly (REP
12.38-150)
2 031E16740 Booklet tamper arm (REP 12.42-
150)
3 127E17690 BM Booklet tamper 1 motor
(MOT12-256) (REP 12.41-150)
4 – Sensor bracket (P/O PL 12.380
Item 1)
5 130E10380 BM paper present sensor (Q12-
170) (REP 12.43-150)
6 130E10360 BM tamper 1 home sensor (Q12-
205) (REP 12.40-150)
7 – Booklet tamper frame (P/O PL
12.380 Item 1)
